Highly integrated & factory prefabricated: HV cabinet, transformer and LV cabinet are fully assembled in factory. Only foundation and cable connection are required on site, greatly shortening construction time.
Space-saving: Occupies over 60% less land than conventional masonry substations, perfect for projects with limited land.
Modular structure: Flexible layout and easy expansion. European type adopts separate compartments for HV, transformer and LV for safer maintenance.
All-weather outdoor performance: Anti-corrosion enclosure, rainproof and dustproof, stable operation under high temperature, freezing and sandy field conditions.
Convenient maintenance: Observation windows and external operating mechanisms allow switching and parameter inspection outside the enclosure.
Cost-effective: Less civil work, lower overall project investment compared with traditional indoor substations.
Note: Pad-mounted (American type) has more compact design with transformer, load switch and fuses in one oil tank. European compact substation has independent separated compartments.
Prefabricated Substation / Compact Substation – Product Series and Specifications
| Power Rating | Up to 10 MVA |
|---|---|
| Primary Voltage | 6 kV, 10 kV, 11 kV, 15 kV, 33 kV, 40.5 kV |
| Transformer Type | Oil-immersed or dry-type |
| High-Voltage Compartment | SF6 gas-insulated ring main unit (RMU) |
| Low-Voltage Compartment | GGD low-voltage switchgear |
| Enclosure Protection Rating | IP33 or customized |
| Frequency | 50 Hz or 60 Hz |
Step-up & distribution for solar power plants, wind farms and other renewable energy projects
Outdoor power supply for residential communities, commercial complexes and industrial parks
Municipal projects: metro supporting facilities, airports, ports, hospitals and parks
Permanent & temporary power supply for mines, oil fields and construction sites
Power distribution for highway service stations and tunnels
Rural electrification projects in remote areas
